Aircraft simulator main control servo motor
Technical data
| Product Model | M290.A01 | Main Control Servo Motor for Aircraft Simulator |
| Performance Parameters | Dimension | 282×318×335 |
| DC Rated Voltage | 540VDC | |
| Rated/Peak Power | 0.35/1.5Kw | |
| Rated/Peak Torque | 200/300N.m | |
| Rated/Peak Speed | 17/85rpm | |
| Maximum Motor Efficiency | ＞90% | |
| Operating Temperature Range | -40℃～65℃ | |
| Motor Weight | 50kg | |
| Cooling Method | Natural Cooling | |
| Protection Grade | IP65 | |
| Insulation Grade | H |
